Genuine Honda Speed Sensor
Speed Control Sensor- Select Vehicle by Model
- Select Vehicle by VIN
Select Vehicle by Model
orMake
Model
Year
Select Vehicle by VIN
For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).
365 Speed Sensors found
Product Specifications- Other Name: Vehicle Speed Sensor
Product Specifications- Replaces: 28810-RPC-003
Honda Pick-Up Assembly (Matsushita)
Part Number: 28820-PWR-013$119.14 MSRP: $172.67You Save: $53.53 (31%)
Product Specifications- Replaces: 28820-RPC-003
Product Specifications- Other Name: Front Speed Sensor; ABS Sensor
- Position: Passenger Side
Product Specifications- Other Name: Front Speed Sensor; ABS Sensor
- Position: Driver Side
Honda Left Front Sensor Assembly
Part Number: 57455-TBA-A03$29.51 MSRP: $41.68You Save: $12.17 (30%)Product Specifications- Other Name: Front Speed Sensor; ABS Sensor
- Position: Driver Side
- Replaces: 57455-TBA-A02
Honda Left Front Sensor Assembly
Part Number: 57455-TR3-A02$37.04 MSRP: $52.32You Save: $15.28 (30%)Product Specifications- Other Name: Front Speed Sensor; ABS Sensor
- Position: Driver Side
Product Specifications- Other Name: Vehicle Speed Sensor; Speed Sensor, Speedometer Sensor
- Replaces: 78410-SR3-003
Honda Left Front Sensor Assembly
Part Number: 57455-SVA-A03$38.68 MSRP: $54.63You Save: $15.95 (30%)Product Specifications- Other Name: Front Speed Sensor; ABS Sensor
- Position: Driver Side
- Replaces: 57455-SVA-A01, 57455-SVA-A02
Honda Pick-Up Assembly (Matsushita)
Part Number: 28810-PWR-013$107.17 MSRP: $151.37You Save: $44.20 (30%)
Honda Right Front Sensor Assembly
Part Number: 57450-TZ5-A02$35.49 MSRP: $50.13You Save: $14.64 (30%)Product Specifications- Other Name: Front Speed Sensor; ABS Sensor
- Position: Passenger Side
Honda Right Front Sensor Assembly
Part Number: 57450-TR3-A02$36.89 MSRP: $52.10You Save: $15.21 (30%)Product Specifications- Other Name: Front Speed Sensor; ABS Sensor
- Position: Passenger Side
Honda Left Front Sensor Assembly
Part Number: 57455-TZ5-A02$36.08 MSRP: $50.97You Save: $14.89 (30%)Product Specifications- Other Name: Front Speed Sensor; ABS Sensor
- Position: Driver Side
Product Specifications- Other Name: Front Speed Sensor; ABS Sensor
- Position: Passenger Side
| Page 1 of 19 |Next >
1-20 of 365 Results
About Honda Speed Sensor
Speed sensor, as the name implies, is a sensor for speed. Technically, the function of the speed sensor is to read how fast you drive or how fast the wheel rotates. The speed sensor is helpful to maintain stability by means of telling the computer when you release pressure to a wheel when you are using ABS. However, when you find you odometer or speedometer doesn't work, or the cruise control doesn't work correctly; when your Honda suddenly loses power; when the fuel economy is not as good as it used to be; when the Check Engine Light is on, there is a chance that your speed sensor is failing. Welcome to our website to finish your easy shopping experience. For your convenience, we offer all Honda OEM speed sensor here with cheap price and the best quality.
Honda Speed Sensor Parts Questions & Experts Answers
- Q: What is the location and removal process for the input shaft (mainshaft) speed sensor on the Honda CR-V?A:2015 and later CR-V models lack an input shaft speed sensor. Find the sensor on the top of the transaxle on Civics, or on the backside of the transaxle on 2014 and earlier CR-V models. Remove the air filter housing and possibly the battery for more space. Disconnect the sensor's electrical connector, remove the mounting bolt and sensor, and discard the O-ring. To install, reverse these steps, using a new O-ring and a special spacer washer for an SLXA transaxle.
- Q: How to replace the output shaft (countershaft) speed sensor on a transaxle on Honda Odyssey?A:Remove the key from the ignition key lock cylinder and the air intake duct. Locate the output shaft (countershaft) speed sensor on top of the transaxle; to remove it, depress the tab to release the electrical connector, disconnect the connector, remove the mounting bolt, and pull the sensor straight up. Disconnect the electrical connector from the output shaft (countershaft) speed sensor, then remove the sensor mounting bolt and pull the sensor straight up. Discard the sensor O-ring. For installation, reverse the removal steps, ensuring to use a new O-ring and tighten the sensor mounting bolt to the specified torque.
- Q: What is the role of the wheel speed sensor in ABS operation and How to remove and install on Honda Prelude?A:Every wheel has a speed sensor that sends to the control module a small AC electrical signal that is crucial for the proper working of the ABS. To get accurate signal generation all the wheels and tires needs to be of the same size and kind; any difference produces the improper signal. The contactless sensor, which can be used to measure the wheel's rotating speed, contains a permanent magnet and a coil; gear pulsars (Tone Rings) are installed on all rotating parts. These pulsars rotate and change the magnetic flux through the coil and produce voltage that follows the frequency and is taken by the ABS control to measure the speed of every wheel. As with other parts of the car, power should be off when uninstalling or installing the sensor, special care should be taken when dealing with the airbag system wiring harness to avoid accidental deployment. They include lifting the car off the ground, disconnecting the sensor's wires, sometimes unbolting some brackets or other parts, and then pulling out the sensor. Aligning the sensor requires careful torque settings of the mounting bolts, proper harness routing without twists and crimps and after that the harness must be connected tightly. After folding the wiring, the use of the ABS checker will allow the signal of the wheel speed sensor to be checked. For inspection, a non-metallic feeler gauge is used to check the gap between the sensor and the pulser; the gap is to be passed at various points to be between 0.020"-0.040" (0.5-1.0mm).
